bending steel pipe
"
Tubo de acero inconsútil de la precisión retirada a frío de los cilindros hidráulicos
Cold Drawn Precision Seamless Steel Tube for hydraulic cylinders Precision pipe: Precision pipe is a kind of seamless steel pipe with high precision and high brightness produced by cold drawing or cold rolling process. Its internal and external diameter can be accurate to within 0.2mm. It not only ensures the bending and torsional strength, but also has light weight. Therefore, it is widely used in the manufacture of precision mechanical parts and engineering structures. It
Tuberías de acero inoxidables 304/316Welded de GB/T12771 12Cr18Ni9 06Cr18Ni11Ti para la entrega líquida
Product Name: GB/T12771 12Cr18Ni9 06Cr18Ni11Ti Welded Stainless Steel Pipes For Liquid Delivery Standard: Size Range: GB/T12771 OD:5-500mm WT:0.5-50mm Length:3-9 M,according to customers' actual application and production. Application: For Liquid Delivery Steel Grade: 304/316/321/347/444 Technology: arc welding Characteristic: Good concentricity Good surface quality Good OD and ID tolerance High Precision Stable quality Smooth Roughness TORICH QUALITY ASSURANCE Table 1
Tubos de acero inconsútil de GB/T 8162 20Mn 25Mn Q235 Q345 para los propósitos estructurales
Seamless Steel Tubes for Structural Purposes GB/T 8162 Spec: Material:10# 20# 45# 20Mn 25Mn Q235 Q345 Size Range: OD:3-1200mm, WT:0.5-200mm, General Length:3-12m Tolerance: According to the following tables or customers’ request. Characteristic: Good concentricity Good OD and ID tolerance High Precision Stable quality Smooth Roughness TORICH QUALITY ASSURANCE Tolerance of the OD &WT: OD Tolerance: Production Method OD Tolerance Hot Rolling(Extrusion) ±1% or ±0.50mm Cold Drawn
GB/T 8163 OD: tubos de acero inconsútil de 4-1200m m para el líquido 10# 20# Q345
Seamless Steel Tubes for Liquid Service GB/T 8163 10# 20# Spec: Material:10# 20# Q295 Q345 st35.8 Size Range:OD:4-1200mm WT:0.3-200mm General Length:3-12.5m Tolerance of the OD &WT: OD Tolerance: Production Method OD Tolerance Hot Rolling(Extrusion) ±1% or ±0.50mm Cold Drawn(Cold Rolled) ±1% or ±0.30mm Tolerance for wall thickness: 1.Wall thickness tolerance of Hot Rolling steel tube: Production Method OD (DN) WT/OD Tolerance Extruded tube ≤102 / ±12.5% or ±0.40mm ＞102 ≤0.05
Tubos de acero sin costura para minería de minerales
Product Name: GB/T 9808 Alloy Steel Grade Oil Drill Mineral Mining Seamless Steel Tubes Size range: O.D.:6-420mm W.T.:0.5-50mm L:4000-12500mm according to customers' actual application and production. Application : For Geological Drill underground for Oil and Mineral, for Mining Exploration,for Wire Line Drill Rod, Casing Tube, Core Barrel Tubes, Couplings Steel Grade: ZT380,ZT490,ZT520,ZT540,ZT590,ZT640,ZT740 Material: 37SiMn 38CrMoAl 30CrMnSi(A) Heat treatment: Normalized,
Tubo inconsútil soldado con autógena ASTM A554 del acero de aleación para 304 306 mecánicos
ASTM A554 Welded Stainless Steel Tubing for Mechanical 304 306 Name stainless steel pipe Items Square tubes, round tubes, oval pipes, special shaped pipes, empaistic pipes, fittings Standard ASTM A554, A249, A269 and A270 Material Grade 201: Ni 0.8%~1% 202: Ni 3.5%~4.5% 304: Ni 8%, Cr 18% 316: Ni 10%, Cr 18% 316L: Ni10%~14% 430: Cr16%~18% Outer Diameter 9.53mm--159mm Thickness 0.3mm - 3.0mm Length 6m or as customers' request a) Outer Diameter: +/- 0.2mm Tolerance b) Thickness
J524 grueso de pared de acero automotriz inconsútil de los tubos 15m m recocido para doblar
Products Description TORICH J524 Seamless Low Carbon Steel Tubing Annealed for Bending and Flaring Standard SAE J524 Material J524 Low Carbon Steel Size WT: 1-15mm; OD: 6-88.9mm; Length: Customer's Requirements Applications For Bending and Flaring to auto parts Test Tension Test, Flaring Test, Flange Test, Reverse Test, Hardness Test, Hydrostatic or Nondestructive Electric Test etc Advantage Cutting For Customer Good Packing with Pallet Better Concentricity Chemical
Caparo hidráulico y neumático tubos de acero EN10305-4 E235 E355 +C +N de la precisión de 2 pulgadas
Hydraulic and Pneumatic Caparo 2 Inch Precision Steel Tubes EN10305-4 E235 E355 +N Hydraulic and Pneumatic Caparo Precision Steel Tubes are manufactured according to technical standard of EN10305-4 E235 E355 +N, with the characteristic of good tolerances and perfect surface quality for both OD and ID, SSID is available according to customers PO and specific requirement. Both OD and ID surface roughness is well controled during cold drawing or cold rolled production, usually
Tubos de acero soldados con autógena de la precisión retirada a frío de GB/T 24187 solos para los evaporadores de los condensadores
GB/T 24187 Cold-drawn precision single welded steel tubes Application:It is suitable for cold drawn precision single-layer welded steel pipes used in the production of condensers, evaporators, fuel pipes, lubricating oil pipes, electric heat pipes, cooler pipes, and general pipes in refrigeration, automotive, electric heating and other industries. Size:L--1.4-4000m WT--0.3-1.3mm OD--3.18-18mm Plating method for outside plating of steel pipe:Electroplating, electroless plating
